- Housing: Anodized Aluminum
- Internal Mechanism: Iron, Steel, & Stainless Steel
- Ball Bearings: Stainless Steel
- Internal Hardware: Stainless Steel
- Packing Seal: FKM
- Body O-ring: FKM
Specs
- Flow Range: 0.2 to 50 GPM (0.76 to 190 LPM); 250:1 Turndown Ratio
- Linear Accuracy: Capable of +/- 0.1% over flow range
- Repeatability: Capable of 0.01%
- Operating Pressure: Up to 150 PSI (10.5 BAR)
- Temperature Range: – 40 to 160°F (- 40 to 71°C)
- Viscosity Range: Will accurately measure liquids up to 50,000 SSU (11,000 CPS)
- Connections: 1-1/2″ NPT Companion Flanges are standard, 1″ & 2″ NPT optional. BSPT, Slip Weld, and ANSI flanges are available upon request.
Diagrams
