Reel Specifications and Dimensions
Additional information
| Weight | 18 lbs |
|---|---|
| Series |
CU |
| 1/2″ Hose Capacity |
50′ |
| Pressure |
300 psi |
| Inlet |
1/2″ NPT(F) |
| Reel Outlet |
1/2″ NPT(F) |
| Hose Included |
No |
| Max Temperature |
150 °F |
| UPC |
699567007579 |
| A | 14.375″ |
| B | 16.75″ |
| C | 13.25″ |
| D | 6″ |
| E | 6.25″ |
| F | 9.25″ |
| G | 2.375″ |
| H | 4″ |
Fluid Path Materials
| Internal Fluid Path | Steel |
| Swivel Assembly | Brass |
| Swivel Seal | Buna |
