Reel Specifications and Dimensions
Additional information
| Series |
30000 |
|---|---|
| 1/4″ Hose Capacity |
425′ |
| 3/8″ Hose Capacity |
300′ |
| 1/2″ Hose Capacity |
200′ |
| 3/4″ Hose Capacity |
100′ |
| 1″ Hose Capacity |
50′ |
| Pressure |
1000 psi |
| Inlet |
1″ NPT(F) |
| Reel Outlet |
1″ NPT(F) |
| Hose Included |
No |
| Max Temperature |
210 °F |
| UPC |
699567019435 |
| Carton Dimensions |
33.75″ x 18″ x 22.25″ |
| A | 20.25″ |
| B | 17.75″ |
| C | 9″ |
| D | 15.75″ |
| E | 25.75″ |
| F | 12″ |
Fluid Path Materials
| Internal Fluid Path | Ductile Iron |
| Swivel Assembly | Steel |
| Swivel Seal | Aflas |
