- Made in the USA (i)
- FRP Construction / Built like a Tank (i)
- Red clear walls (i)
- Large flat-walls to fit more entry fittings
- Interchangeable Dispenser Frame (i)
- Electrical Offset (EO) Frame (i)
- Sized & tailored to any dispenser model (i)
- Stabilizer brackets included and pre-plumbed (i)
- Split UDC provides maximum workspace access
- Easy slurry pour joint at center
- Height is adjustable in the field
- Kitted: Includes installation accessories and slurry (i)
- UL & CUL Listed
- 30 Year Warranty (i)
Specs
- Material: Tank-spec Fiberglass (i) – UL & CUL Listed
- Standard sizes: All sumps are 24” wide and 30” deep.
- Large: 42” long. Medium: 30” long.
- Interchangeable dispenser frame adds a 1-1/2” tall water splash lip but resides inside the dispenser footprint.
- Field cut down is possible to an overall depth of 24”
- Standard height of top section is 14”
- Standard height of the bottom section is 16”
- Contact us to customize this product (i) .
- EO frame accommodates multiple 1” and 3/4” conduits.
Options
- Recommended: F-Series all-fiberglass entry fittings for FRP pipe, PE pipe or conduit.
- Optional adders for additional sump height
- Option for a factory-sealed and tested U-channel (See “B-7000 Solid”)
- Optional oversized UDC for DEF containment (i)
- Optional Electrical Offset frame for all common retail sumps including: Encore, Ovation, Vista, Advantage, Select, Reliance and the Pacifica.
- Optional vapor bracket
- Optional product and vapor shear valves
- Option for factory-installed entry fittings (i)
- Option to customize this product to meet your needs (i)
