- Made in the USA (i)
- FRP Construction / Built like a Tank (i)
- Red clear walls (i)
- Extra-large flat-walls to fit more entry fittings
- 40% wider than the B-8000 sump
- 16% deeper than the B-8000 sump
- Interchangeable Dispenser Frame (i)
- Electrical Offset (EO) Frame (i)
- Sized & tailored to any dispenser model (i)
- Stabilizer brackets included and pre-plumbed (i)
- Factory-tested (i)
- Kitted: Includes installation accessories (i)
- Third Party Approved
- UL & CUL Listed
- FDEP Approved: EQ 615
- 30 Year Warranty (i)
Specs
- Material: Tank-spec Fiberglass (i) and epoxy coated steel
- Standard sizes: All sumps are 28” wide and 35-1/2” deep.
- Large: 42” long. Medium: 30” long. Small: 25-1/2” long.
- Interchangeable dispenser frame adds a 1-1/2” tall water splash lip but resides inside the dispenser footprint.
- Contact us to customize this product (i) .
- EO frame accommodates multiple 1” and 3/4” conduits.
Options
- Recommended: F-Series all-fiberglass entry fittings for FRP pipe, PE pipe or conduit.
- Option for depth and height adders
- Optional oversized UDC for DEF containment (i)
- Optional Electrical Offset frame for all commercial dispensers and common retail models including: Encore, Ovation, Vista, Advantage, Select, Reliance and the Pacifica.
- Optional vapor bracket
- Optional factory-installed product and vapor shear valves
- Option for factory-installed entry fittings (i)
- Option to customize this product to meet your needs (i)
