AVR 310227001-03T0800514 For Blackmax TTI 7000 8750 Watt Voltage Regulator
Part Number:
AVR-310227001-03T0800514. It is compatible with Blackmax TTI Part 310227001-03T0800514.
Product Features:
1.Built-in Full-Wave Output Bridge Rectification.
2.Voltage Output Increase with Loading.
3.Stable Voltage Output with Negative Voltage Feedback.
4.Over Voltage, Over Current and Short Circuit Protection.
5.Large Manual Adjustable Voltage Output Range of 160V ~ 260V for 240V output.
Technical Specifications:
1.Maximum Output: DC 90V 3.5A.
2.Excitation Voltage: 90V ~ 100V.
3.Feedback Voltage: 14V ~ 24V with an Average of 18V.
4.Frequency: 50/60Hz.
5.AC Voltage Output: 120V/240V.
6.Auto Voltage Adjusting Accuracy: ≤ ±1%.
7.Maximum Temperature Rise: 130C or 266F.
8.Continuous Working Time: ≥ 20 Hours.
9.Installation-Center Distance: 140 ± 1mm (about 5.5 in).
